POWERWALKER UPS VFI 3000TGB(PS) (10122100)

Name: POWERWALKER UPS VFI 3000TGB(PS) (10122100)
Brand: POWERWALKER
Price: 619.49 EUR
Availability: InStock

Κατασκευαστής: POWERWALKER
Κωδικός Προϊόντος: VFI 3000TGB(PS)
Διαθεσιμότητα: Διαθέσιμο

Τιμή: 619,49€
Χωρίς ΦΠΑ: 499,59€

Ποσότητα:

0 αξιολογήσεις | Γράψτε μια αξιολόγηση

Περιγραφή Χαρακτηριστικά Αξιολογήσεις (0) Σχετικά Προϊόντα (8)

High efficiency results in energy saving with output power factor 0.9 Human Interface Device (HID) compatible USB connection (no additional drivers needed) Wide input voltage range for all environments and support for AC generator Available with integrated batteries

The PowerWalker VFI 1000-10000 TG/TGB/TGS offer a professional solution for home and office environment. They are available with different designs:
TG: With internal battery; ranges from 1000-3000VA
TGB: With internal battery and battery connector for external battery packs; ranges from 1000-10000VA
TGS: Without internal batteries, but with a strong charger and battery connector; ranges from 1000-10000VA

The VFI TG/TGB/TGS series are detected as Human Interface Device (HID) Power Device by the internal O/S drivers and can be managed without additional software. It finds its application in all dedicated systems for kiosks, ATMs as well as in high security level systems, where additional software is not allowed (i.e. banking).

Technical specification

General features
Type	Online
Power capacity	3000VA / 2700W
Output Power Factor	0.90
Input
Input Voltage Range	176-300 VAC or 80x285 VAC in bypass mode
Max THDi	<5%
Input PF	≥ 0.99 at full load
Frequency Range	40Hz - 70Hz
Frequency (Synchronized Range)	45Hz - 55Hz or 54Hz - 66Hz
Output
Nominal Output Voltage	220/230/240 VAC
Pure Sine Wave	Yes
THDv	≤2% Full Linear Load; ≤5% Non-Linear Load
Voltage Regulation (Bat. Mod.)	±2%
Frequency (Battery Mode)	±0,05Hz
Technical details
Load Crest Ratio	3:1
Transfer Time [AC to Battery]	0ms
Transfer Time [Inverter to Bypass]	4ms
Generator support	Yes
Overload Capacity	Line: constant @100%-105%; 1min @105%-130%; 10s @130%-150%; 300ms @>150%; bypass at higher; BAT: 10s @100%-150%; cut-off at higher
External Battery Connection	Yes
Charger	1.5A
Fan Logic	Always ON; Low speed: bypass/ECO or line mode with load below 70% High speed: Battery mode or line mode with load above 70%
Efficiency
LINE mode full Load	90.0%
Batteries and autonomy time
Batteries	6x 12V/9Ah
DC Voltage	6 x 12V

Recharge Time	4h to 90%
Full Load Backup Time	3.9min
Half Load Backup Time	11.7min
Connections and communication
IEC C13 Outlet	4
IEC C19 Outlet	1
Input	C20
Software	WinPower
USB port	Yes
HID Support	Yes
RS-232 Port	Yes
Extension Slot	Yes, 1
EPO Port	Yes
Environment
Noise Level	< 50dB
Temperature	0°C – 40°C
Humidity	0% - 95% RH (non-condensing)
Logistics
IEC 62040-3 classification	VFI-SS-311
Package Content	UPS, Manual, Software CD, USB Cable, Input Power Cable, 2x IEC Cable
Manual Languages	EN/DE/PL
EAN	4260074979770
Width	190 mm
Height	328 mm
Depth	399 mm
Weight	22.2 kg
Giftbox - Width	324 mm
Giftbox - Height	464 mm
Giftbox - Depth	500 mm
Giftbox - Weight	24.6 kg
Pcs. per box	1
Pcs. per pal	14
